Internal Models (HM25c)
334784G 53
Internal Models (HM25c)
Parts List
WLD
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
Ref. Part Description Qty.
201 17E019 MODULE, GCA, pattern control 1
202 17M504 HARNESS, PC-8 internal 1
203 FRAME, cord grip, 4-position 1
204 125856 SCREW, 8-32, serrated flange 4
205 121000 CABLE, can female/female 0.5m 1
206 128117 CONNECTOR, plug, 3.81mm, 12-position 1
207 128147 CONNECTOR, plug, 3.81mm, 8-position 2
208 129538 CONNECTOR, plug, 3.81mm, 4-position 1
209 129540 CONNECTOR, plug, 3.81mm, 6-position 2
