Technical Specifications
64 334784G
Technical Specifications
Trigger Specifications: Encoder Specifications:
Run Up Specifications:
InvisiPac Pattern Controller
Description Value Details
Input Power External models only 100-240 VAC, 50/60 Hz, 2A max
Gun Outputs 8 24 VDC, 1A each, 6A max total
Total Gun
Wattage
120 W (internal models - HM25c)
90 W (internal models - HM25 and HM50)
150 W (external models)
- - - - -
Trigger Inputs 4 NPN or PNP or dry contact
Trigger Excitation 24 VDC - - - - -
Encoder 2 (PC-8e only) Quadrature differential line driver
Encoder Excitation 15 VDC - - - - -
Run Up Control 2 (PC-8e only) I/P (4-20mA) or V/P (0-10V)
Run Up Excitation 24 VDC - - - - -
PLC Enable/Disable YES 0-30VDC, min 10 V to assert
PLC Program
Select Bit
4
Select up to 15 unique programs
PLA Alarm Output YES 0-250 VAC (dry contact output)
Integrated Power
Supply YES
24 VDC, 150 W (internal models - HM25c)
24 VDC, 120 W (internal models - HM25 and HM50)
24 VDC, 150 W (external models)
Program Storage 50 - - - - -
Beads Per Output
24
Each bead can be stitched, allowing many more than
24 dots
Distance Accuracy 1 mm, 0.1 in. - - - - -
Time Accuracy 1 ms - - - - -
Enclosure
Environmental Rating
IP54
Resistant to dust and splashing water
Ambient Temperature 32° - 120°F, 0° - 50°C - - - - -
Description
Kit Part
24X446 24X447
Sensor type Diffuse Retro-reflective
Excitation 10 - 30 VDC
Sensing range 200 mm 5.0 m
Output type NPN/PNP
Description
Kit Part
24X448
Excitation 10 - 30 VDC
Pulses per revolution 1000
Output type 5 VDC (TTL/RS422)
Differential line driver
Description
Kit Part
17E020
Excitation 21.6 - 26.4 VDC
Control voltage 0 - 10 VDC
