Dimensioned Drawings
334784G 63
Couplers
Run Up Controller
Part L L1 L2 D Graco Encoder
Shaft
Customer Shaft
(Bore)
17F540
1 in.
(25.4 mm)
0.374 in.
(9.5 mm)
0.25 in.
(6.4 mm)
0.984 in.
(25.0 mm)
10 mm
6 mm
17F541 8 mm
17F542 10 mm
17F543 12 mm
17F544 1/8 in.
17F545 3/16 in.
17F546 1/4 in.
17F547 3/8 in.
17F548 1/2 in.
17F549
1.17 in.
(29.7 mm)
0.394 in.
(10.0 mm)
0.38 in.
(9.7 mm)
1.457 in.
(37.0 mm)
15 mm
17F550 5/8 in.
17F551 3/4 in.
ti31584a
ti31585a
1.97 in
(50 mm)
1.97 in
(50 mm)
4.49 in
(114 mm)
4.016
(102
m
