LazerGuide 1700
4 Instructions
LazerGuide 1700
LineLazer V 3900, 5900 & 200HS
1. Remove battery cover.
2. Attach ON/OFF switch to desired location on the
handle bar.
3. Attach laser to desired location on the gun arm.
4. Route wires up to the battery and connect to the (+)
and (-) terminals.
5. Connect the switch leads to the laser wire harness.
6. Reattach battery cover.
7. Turn on laser and position dot underneath gun
head.
NOTICE
Do not connect GL1700 directly to a generator source
as it can create over voltage and damage to the elec-
tronics.
ti27815a
ti27818a
