LazerGuide 1700
6 Instructions
9. Route switch wires down to battery and connect to
the (+) and (-) terminals, and route jumper through
gun cable hole.
10. Connect the jumper to the laser wire harness, and
secure all cables as necessary.
11. Reinstall the battery.
12. Replace the coiled hose.
13. Turn on laser and position dot underneath gun
head.
NOTICE
Do not connect GL1700 directly to a generator source
as it can create over voltage and damage to the elec-
tronics.
