Graco LD Series User Manual

Models
313431A 3
XD Series (Parts List page 26)
**Each HS Model hose reel shown in the table below is available in either white or metallic blue. The last character of
each Model No. indicates the hose reel color. For example: A = white, B = metallic blue, F = yellow. (Other color
choices may be available from your Graco Distributor.) On the table below this last character is represented by the
generic # symbol. For example to show the complete model number for a white HSL2D# model hose reel, the # sym-
bol in the table is replaced with “A”. The complete model number is: HSL2DA.
Model
No.** Size Type
Pressure
Rating
psi (bar) Media
Connection Size Line
Size
(inches)
Length
(feet)Inlet Outlet
HSL2D# 10 Bare 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npsm(f)
3/8 50
HSL6D# 20 Bare 300 (20.7)
Air/Water
1/2 npsm(m) 1/2 npsm(f)
1/2 50
HSL25# 10 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npt(m)
3/8 50
HSL56# 20 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npt(m)
3/8 65
HSL65# 20 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 1/2 npt(m)
1/2 50
HSM3B# 10 Bare 2000 (138)
Oil
1/2 npsm(m) 1/2 npsm(f)
1/2 35
HSM6D# 20 Bare 2000 (138)
Oil
1/2 npsm(m) 1/2 npsm(f)
1/2 50
HSM33# 10 Hose 2000 (138)
Oil
1/2 npsm(m) 1/2 npt(m)
1/2 35
HSM65# 20 Hose 2000 (138)
Oil
1/2 npsm(m) 1/2 npt(m)
1/2 50
HSH15# 10 Hose 5000 (344.7)
Grease
3/8 npsm(m) 1/4 npt(m)
1/4 50
HSH1D# 10 Bare 5000 (344.7)
Grease
3/8 npsm(m) 3/8 npsm(f)
1/4 50
HSH5D# 20 Bare 5000 (344.7)
Grease
3/8 npsm(m) 3/8 npsm(f)
3/8 50
HSH55# 20 Hose 4000 (275.8)
Grease
3/8 npsm(m) 1/4 npt(m)
3/8 50
