Graco LD Series User Manual

Models
2 313431A
Models
LD Series (Parts List, page 23)
*Each HR or HP Model hose reel shown in the tables below is available in several colors. The last character of each
Model No. indicates the hose reel color. For example: A = white, B = metallic blue, C = red, D = black, E = Mercedes
blue, or F = yellow. (Other color choices may be available from your Graco Distributor.) On the table below this last
character is represented by the generic # symbol. For example, to show the complete model number for a white
HRL56# model hose reel, the # symbol in the table is replaced with “A”. The complete model number is: HRL56A.
SD Series (Part List page 24)
Model
No.* Size Type
Pressure
Rating
psi (bar) Media
Connection Size Line
Size
(inches)
Length
(feet)Inlet Outlet
HRL56# 20 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npt (m)
3/8 65
HRL65# 20 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 1/2 npt (m)
1/2 50
HRM65# 20 Hose 2000 (138)
Oil
1/2 npsm(m) 1/2 npt(m)
1/2 50
HRH55# 20 Hose 4000 (275.8)
Grease
3/8 npsm(m) 1/4 npt(m)
3/8 50
Model
No.* Size Type
Pressure
Rating
psi (bar) Media
Connection Size Line
Size
(inches)
Length
(feet)Inlet Outlet
HPL2D# 10 Bare 300 (20.7)
Air/Water
3/8 npsm(m) 1/2 npsm(f)
3/8 50
HPL6D# 20 Bare 300 (20.7)
Air/Water
1/2 npsm(m) 1/2 npsm(f)
1/2 50
HPL23# 10 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npt(m)
3/8 35
HPL25# 10 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npt(m)
3/8 50
HPL56# 20 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 3/8 npt(m)
3/8 65
HPL33# 10 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 1/2 npt(m)
1/2 35
HPL65# 20 Hose 300 (20.7)
Air/Water
1/2 npsm(m) 1/2 npt(m)
1/2 50
HPM3B# 10 Bare 2000 (138)
Oil
1/2 npsm(m) 1/2 npsm(f)
1/2 35
HPM6D# 20 Bare 2000 (138)
Oil
1/2 npsm(m) 1/2 npsm(f)
1/2 50
HPM33# 10 Hose 2000 (138)
Oil
1/2 npsm(m) 1/2 npt(m)
1/2 35
HPM65# 20 Hose 2000 (138)
Oil
1/2 npsm(m) 1/2 npt(m)
1/2 50
HPH1D# 10 Bare 5000 (344.7)
Grease
3/8 npsm(m) 3/8 npsm (f)
1/4 50
HPH5D# 20 Bare 5000 (344.7)
Grease
3/8 npsm(m) 3/8 npsm (f)
3/8 50
HPH15# 10 Hose 5000 (344.7)
Grease
3/8 npsm(m) 1/4 npt (m)
1/4 50
HPH23# 10 Hose 4000 (275.8)
Grease
3/8 npsm(m) 1/4 npt (m)
3/8 35
HPH55# 20 Hose 4000 (275.8)
Grease
3/8 npsm(m) 1/4 npt (m)
3/8 50
