Technical Data
32 313431A
Dimensions
HR Models
† Measurement taken from base to top of bolts.
◆ Measurement taken from edge of spool to front of arm.
B
D
A
C
F
E
G
Pressure Size ABCDE†FG◆
Low 20
3.5 inches
(89 mm)
7.8 inches
(197 mm)
4.7 inches
(120 mm)
9 inches
(229 mm)
21.8 inches
(554 mm)
7.0 inches
(177 mm)
19.2 inches
(487 mm)
Medium 20
High 20
