Graco LP 555 - Control Box Parts List

Control Box
52 3A4203B
Control Box Parts List
Ref. Part Description
Qty.
2 117828 PACKING, o-ring
1
3 111457 PACKING, o-ring
1
4 111600 PIN, grooved
1
5 277364 GASKET, seat, valve
1
6 115494 SCREW, mach,
Phillips, pan hd
6
7 115498 SCREW, mch,
slot/hex, wash hd
1
11 116167 KNOB, potentiometer
1
12 117501 SCREW, mach, hex
washer hd
4
15 15G455 MANIFOLD, fluid
1
16 FILTER, fluid
1
17P314 30 mesh
17P315 60 mesh, original
17P316 100 mesh
17 287902 CAP, manifold,
includes 18
1
18 15B071 INSERT, filter
1
19 15B118 BUSHING, motor wire
1
20 15B120 GROMMET,
transducer
1
24 162453 NIPPLE, (1/4 npsm x
1/4 npt)
1
26 15E022 SEAT, valve
1
27 187625 HANDLE, valve, drain
1
30 195428 BOOT, toggle
1
35 239914 VALVE, drain,
includes
5, 26
1
36 224807 BASE, valve
1
37 17D888 POTENTIOMETER,
assembly
1
38 243222 TRANSDUCER,
pressure control,
includes 3
1
47 117493 SCREW, mach, hex
washer hd
4
48 276868 BOX, control
1
49 CONTROL, board
1
555 models:
246378 110V
246380 230V
655/S2550 models:
17N505 110V
24X751 230V
50 17N274 DIGITAL, display
includes 51, 52
2
51 17M694 LABEL, control
1
52 17M698 LABEL, control,
display
1
56 CORD, power 1
110V models:
253368 UK plug
230V models:
253369 CEE 7/7 plug
58 SWITCH, toggle
1
195429 110/120V
117492
230V,
Europe/Asia/ANZ/UK
101 158674
O-ring, packing
1
102 17P738 LABEL, control
1
Ref. Part Description
Qty.
