Component Identification A45 and A60
10 332697C
Component Identification A45 and A60
A Airless spray gun Dispenses fluid.
B Power switch Turns sprayer ON and OFF.
C Pressure control knob Increases (clockwise) and decreases (counter-clockwise) fluid pressure in
pump, hose, and spray gun.
C1 Setting Indicator To select function, align symbol on pressure control knob with setting
indicator, page 13.
D Pump fluid outlet fitting Threaded connection for paint hose.
E InstaClean™ fluid filter
(A60 Sprayer Only)
• Filters fluid coming out of pump to reduce tip plugging and improve
finish.
• Self cleans only during pressure relief.
F Power-Piston™ Pump, (Not
shown. Behind Easy Access door)
(A60 Sprayer Only)
Pumps and pressurizes fluid and delivers it to paint hose.
F1 Easy Access door
(A60 Sprayer Only)
Easy Access door permits quick access to outlet valve. To remove door,
insert flat blade of screwdriver into slot on the bottom of the door
(as shown on page, 11).
G Suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Prime/Spray valve • PRIME position directs fluid to prime tube.
• SPRAY position directs pressurized fluid to paint hose.
• Automatically relieves system pressure in overpressure situations.
K Ball Knocker
(A60 Sprayer Only)
Automatically taps the inlet ball when you turn the sprayer on.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
Q Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip • Atomizes fluid being sprayed, forms spray pattern and controls fluid
flow according to hole size.
• Reverse unclogs plugged tips without disassembly.
S Gun trigger safety lever (page 13) Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
U Power Flush attachment Connects garden hose to suction tube for power flushing water-based
fluids.
V Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.
W Hose wrap Rack Stows paint hose.
X Pail hanger For transporting pail by its handle.
Y Power Cord Supplies sprayer with electricity.
Z Power Flush Adapter
(A60 Sprayer Only)
Adapts suction tube (G) to Power Flush attachment (U).
AA Pump Priming Button
(A45 sprayer only)
Manually taps inlet ball to loosen if stuck.
AB Garden Hose Adapter Connects to Power Flush Attachment and garden hose.
