Graco Magnum Pro Plus A30 Repair Manual

Specifications
332697C 3
Specifications
This equipment is not intended for use with flammable or combustible materials used in places such as cabinet
shops or other “factory”, or fixed locations. If you intend to use this equipment in this type of application, you must
comply with NFPA 33 and OSHA requirements for the use of flammable and combustible materials.
Model Name Series
Maximum
Dispense
Rate lpm
(gpm)
Hose Length and
Diameter
Gun
Model
Maximum Working
Pressure
bar MPa PSI
A20 A
0.91 lpm
(0.24 gpm)
6.4 mm x 7.5 m
(1/4 in. x 25 ft)
SG2 207 21 3000
A30 A and B
1.02 lpm
(0.27 gpm)
6.4 mm x 7.5 m
(1/4 in. x 25 ft)
SG3 207 21 3000
A45 A and B
1.17 lpm
(0.31 gpm)
6.4 mm x 15 m
(1/4 in. x 50 ft)
SG3 207 21 3000
A60 A
1.44 lpm
(0.38 gpm)
6.4 mm x 15 m
(1/4 in. x 50 ft)
SG3 207 21 3000
