Technical Data
56 332697C
Technical Data
A20 A30
Working pressure range 0-207 BAR, 0-21 Mpa (0-3000 psi)
Electric Motor 4.5A
(open frame, universal)
Operating horsepower 3/8 1/2
Maximum delivery (with tip) .91 lpm (.24 gpm) 1.02 lpm (.27 gpm)
Paint hose 6.4mm X 7.5 m (1/4 in. x 25 ft)
Maximum tip hole size 0.015 in. (0.38 mm)
Weight, Sprayer only 4.5 kg (10.0 lb) 5.4 kg (12 lb)
Weight, sprayer, hose, & gun 6.0 kg (13.3 lb) 6.9 kg (15.2 lb)
Dimensions (Upright):
Length 35.2 cm (13.8 in) 36.8 cm (14.5 in)
Width 30.7 cm (12.1 in) 31.5 cm (12.4 in)
Height 35.1 cm (13.8 in) 45.5 cm (17.9 in)
Dimensions (Folded):
Length N/A
Width N/A
Height N/A
Power cord 1.0 mm², 3-wire, 1.8 m (6 ft.)
Fluid inlet fitting 1/4 npsm external thread
Fluid outlet fitting 3/4 in. internally threaded
(standard garden hose)
Inlet screen (on suction tube) 1190 micron (16 mesh)
Wetted parts, pump and hose stainless steel, zinc plated carbon steel, brass, ultra-high molecular weight poly-
ethylene (UHMWPE), Carbide, Nylon, Aluminum, PVC, polypropylene,
fluroelastomer
Wetted parts, gun aluminum, brass, carbide, nylon, ultra-high molecular weight polyethylene
(UHMWPE), zinc
Generator requirement 1500 Watt minimum
Electrical power requirement 220-240V AC 50/60 Hz, I phase, 10A
Storage temperature range◆❖ -35° to 71° C (-30° to 160° F)
Operating temperature range 4° to 46° C (40° to 115° F)
When pump is stored with non-freezing fluid. Pump damage will occur if water or latex paint freezes in pump.
Damage to plastic parts may result if impact occurs in low temperature conditions.
Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
