Technical Data
332697C 57
A45 A60
Working pressure range 0-207 BAR, 0-21 Mpa (0-3000 psi)
Electric Motor 4.5A
(open frame, universal)
6.5A
(open frame, permanent magnet DC)
Operating horsepower 5/8 7/8
Maximum delivery (with tip) 1.17 lpm (.31 gpm) 1.44 lpm (.38 gpm)
Paint hose 6.4mm X 15 m (1/4 in. x 50 ft)
Maximum tip hole size 0.017 in. (0.43 mm) 0.019 in. (0.48 mm)
Weight, sprayer only 10.6 kg (23.3 lb) 15 kg (33.0 lb)
Weight, sprayer, hose, & gun 12.7 kg (26.5 lb) 17.1 kg (37.7 lb)
Dimensions (Upright):
Length 49.0 cm (19.3 in) 54 cm (21.3 in)
Width 38.9 cm (15.3 in) 43.8 cm (17.3 in)
Height 94.0 cm (37.0 in) 94.5 cm (37.2 in)
Dimensions (Folded):
Length 49.0 cm (19.3 in) 54 cm (21.3 in)
Width 38.9 cm (15.3 in) 43.8 cm (17.3 in)
Height 74.2 cm (29.2 in) 74.7 cm (29.4 in)
Power cord 1.0 mm², 3-wire, 1.8 m (6 ft)
Fluid inlet fitting 1/4 npsm external thread
Fluid outlet fitting 3/4 in. internally threaded (standard gar-
den hose)
7/8 - 14 UNF external thread
Inlet screen (on suction tube) 1190 micron (16 mesh) 1680 micron (12 mesh)
Wetted parts, pump and hose stainless steel, zinc plated carbon steel,
brass, ultra-high molecular weight poly-
ethylene (UHMWPE), Carbide, Nylon,
Aluminum, PVC, polypropylene,
fluroelastomer
stainless steel, zinc plated carbon steel,
brass, leather, ultra-high molecular
weight polyethylene (UHMWPE), Car-
bide, Nylon, Aluminum, PVC,
polypropylene, fluroelastomer
Wetted parts, gun aluminum, brass, carbide, nylon,
ultra-high molecular weight polyethylene (UHMWPE), zinc
Generator requirement 1500 Watt minimum
Electrical power requirement 220-240V AC 50/60 Hz, I phase, 10A
Storage temperature range◆❖ -35° to 71° C (-30° to 160° F)
Operating temperature range✔ 4° to 46° C (40° to 115° F)
◆ When pump is stored with non-freezing fluid. Pump damage will occur if water or latex paint freezes in pump.
❖ Damage to plastic parts may result if impact occurs in low temperature conditions.
✔ Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
