Cleanup
3A4416A 25
17. Turn pressure control knob to the low-
est setting.
18. Stop triggering gun. Engage the trigger
lock.
19. Turn Prime/Spray valve down to
PRIME position.
20. Turn ON/OFF switch to OFF position.
Cleaning InstaClean
™
Fluid Filter (ProX only)
The InstaClean Fluid Filter prevents particles
from entering paint hose. After each use,
remove and clean it to ensure peak
performance.
1. Perform Pressure Relief Procedure,
page 13.
2. Disconnect airless spray hose (A) from
sprayer.
3. Unscrew outlet fitting (B).
4. Remove InstaClean Fluid Filter (C).
5. Check InstaClean Fluid Filter (C) for
debris. If needed, clean filter with water
or flushing fluid and a soft brush.
a. Install closed (square) end of
InstaClean Fluid Filter (C) in
sprayer.
b. Screw outlet fitting (B) into sprayer.
6. Tighten outlet fitting and reconnect hose
(A) to sprayer. Use a wrench to tighten
securely.
ti27151a
ti27120a
27179a
ti27122a
