(Numberedsteps1–4correspondtothenumbered
columnsintheProControl1KEPlusModelSelection
Matrix,page5.)
1.Chooselevelofapplicationcontrolneeded.
2.Determine󰘱owmeter,ifapplicableforlevelof
controlchosen.(GunAtomizingAirControland
ClosedLoopFluidPressureControlunitsdonot
usea󰘱owmeter.)
TheG3000meteristhestandardrecommended
meter.
Note: Note:
Note:
Notallmetersareapprovedforhazardous
locations.Seeyour󰘱owmetermanualfordetails.
3.Determine󰘱uidpressureregulator,ifapplicable
forthelevelofcontrolchosen.(TheGun
AtomizingAirControlunit,25B289,doesnotuse
a󰘱uidpressureregulator.)
TheGraco24C3751:1LowFlowRegulatoris
standard.
4.SelectbaseProControl1KEPlusmodelpart
numberfromtheProControl1KEPlusModel
SelectionMatrix,page5.
Note
ProControl1KEPlusunitscomewith5ft.
(1.5m)cablelengthstoallowmounting
theusercontrolinterface(ADCM)nearthe
󰘱uidpanel.Ifamoreremotemountingis
required,purchasetheappropriateextension
cables,availablein50ft.(16m)lengths.
SeeAccessories,page77.
63A6948A
