Component Identification
3A0153E 5
Component Identification
*NOTE: Filter assembly is reverse-threaded. Turn left (or counter-clockwise) to tighten,
turn right (or clockwise) to loosen.
ti15479a
D
Fa
E
R
K
M
C
Y
T
S
W
B
D
P
A
Fa
Fb
G
J
H
N
Z
L
A ProShot Cordless Paint Sprayer
B Sprayer Hook
C Outlet Valve Repair Access
D
ProShot Spray Tip/Guard Assembly
(411, 515 included)
E Tip Filter (*Reverse Threaded)
Fa Standard Suction Tube (sprays ceilings and walls)
Fb Specialized Suction Tube (sprays floors)
G Pump Armor Concentrate (4 oz.)
H Fine-Finish Optimizer with Storage/Cleaning Tool
J Material Cup Cover and Seal
K Material Cup (32 oz)
L Power Cord Converter (258859 only)
M Prime/Relief Valve
N Lithium Ion Premium Power Battery Charger
P Material Cup Liners (5 included)
R Lithium Ion Premium Power Battery (2 included)
S Battery Release Button
T Battery Status Indicator Light
W Sprayer Trigger
Y Sprayer Trigger Lock
Z ProShot Case
