Graco PROX17 User Manual

X5: 262800, 17K437 Stand Sprayer Parts
36 3A3208B
X5: 262800, 17K437 Stand Sprayer Parts
51
2
5
6
4
22a
10
10a
10b
12
16a
16b
16
19
8a
8b
48
8
31
17
29c
29a
29b
29
20
19a
22
30
37
39
36
34
38
35
40
52
19b
13a
13
ti28224a
41
1
33
33a
33b
33c
1
2
3
4
5
6
Ref. Torque
20-25 in-lb (2.3-2.8 N•m)
26-32 in-lb (2.9-3.6 N•m)
25-35 in-lb (2.8-4.0 N•m)
80-90 in-lb (9.0-10.0 N•m)
12-16 in-lb (1.4-1.8 N•m)
36-42 in-lb (4.0-4.7 N•m)
1
2
3
4
5
6

Graco PROX17 Specifications

General

Max Tip Size	0.017 inches
Max Pressure	3000 PSI
Hose Length	50 feet
Type	Airless
Power Source	Electric
Voltage	120 V
Spray Tip Included	Yes
Amp Draw	15 amps
Weight	32 lbs
