Graco PT2500 - Service and Repair; Inlet Check Valve; Outlet Check Valve; Pressure Control

19
307-711
REPAIR INSTRUCTIONS
LUBRICATE AND
TORQUE TO
320–360 in–lb
(36–41 N.m)
Fig 15
21
22a
22b
26a
26
27
25
24
28d
28f
28c
28e
28b
28a
TORQUE T O
125–150 in–lb
(14–17 N.m)
TORQUE TO
280–300 in–lb
(32–34 N.m)
LUBRICA TE AND T ORQUE TO
170–200 in–lb
(19–23 N.m)
C
TORQUE TO
125–150 IN–LB
(14–17 N.M)
4
4a
38
37
36
APPL Y THREAD SEALANT
66
35
3
67
APPLY
THREAD
SEALANT
20
LUBRICATE
INTERNAL
THREADS
28
18a
Start Switch located
in switch box
0284
DO NOT AL TER POSITION OF NUT
