Graco PT2500 - Danger Labels; FIRE AND EXPLOSION HAZARD; SKIN INJECTION HAZARD

 307-711
WELCOME T O GRACO’S PAINTER’S TEAM
Before you use the PT2500 Sprayer, please read this entire instruction manual.
It contains important information that will help you operate the sprayer safely and
efficiently, and will help you keep the sprayer in top operating condition.
TABLE OF CONTENTS
Terms 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PT2500 Sprayer Description 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Avertissement (French W arnings) 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Advertencia (Spanish W arnings) 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Startup 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Application Methods 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Repair Instructions 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Drawings and Lists 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Numbers 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data Back Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty Back Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TERMS
Be sure you read and understand each of these terms be -
fore
reading the rest of the manual.
WARNING Alerts the user to avoid or correct condi-
tions
which could cause bodily injury .
CAUTION Alerts user to avoid or correct conditions
which
could damage or destroy the equipment.
PRESSURE RELIEF PROCEDURE A safety proce-
dure
for relieving fluid pressure in the system.
FLUID INJECTION INJURY A serious injury, which
may appear to be only a simple cut, caused by the high
pressure injection of fluid directly into the body .
NOTE Gives additional explanation of a procedure or
helpful
hints.
Hazard of Using Fluids Containing Halogenated Hydrocarbons
Never
use 1,1, 1–trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids contain -
ing such solvents in this equipment. Such use could result in a serious chemical reaction, with the possibility of
explosion,
which could cause death, serious bodily injury and/or substantial property damage.
Consult your fluid suppliers to ensure that the fluids being used are compatible with aluminum and zinc parts.
WARNING
A
torque wrench is needed to properly check and tighten the valves and screws on this sprayer . Failure to torque
these parts at the specified intervals (see page 13) will result in leaking and serious damage to the sprayer .
CAUTION
