24 307-711
TECHNICAL
DA
TA
Power
Requirements
120 V
AC, 60 Hz, 1 Phase, 15 AMP minimum
.
. . . . . . . . . . . . .
Pressure
Operating Range
0–3000 psi (0 – 210 bar)
.
. . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum
Delivery
0.28 GPM (1.1 liter/min)
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power
Cord
No. 16 A
WG, 3 wire, 8’6” (2.6 m) long
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inlet
Paint Strainer
16 mesh
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid
Outlet Nipple
1/4 npsm (m).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight
– without hose and gun
33 lb (14.8 Kg)
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions Height: 20” (508 mm).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Width: 17.5” (444.5 mm)
Depth: 17.5” (444.5 mm)
W
etted Parts
Stainless Steel, Zinc-Plated Steel, Carbide,
.
. . . . . . . . . . . . . . . . . . . . . .
Aluminum,
Nylon, Delrin
, Monel
Delrin
is a registered trademark of the DuPont Company
THE
GRACO W
ARRANTY AND DISCLAIMERS
WARRANTY
Graco
warrants all equipment manufactured by it and
bearing its name to be free from defects in material and
workmanship
on the date of sale by an authorized Graco distributor to the original purchaser for use. As pur
-
chaser’s
sole remedy for breach of this warranty
, Graco will, for a period of twelve months from the
date of sale,
repair
or replace any part of the equipment proven defective. This warranty applies only when the equipment is
installed,
operated and maintained in accordance with Graco’
s written recommendations.
This warranty does not cover, and Graco shall not be liable for, any malfunction, damage or wear caused by
faulty
installation, misapplication, abrasion,
corrosion, inadequate or improper maintenance, negligence, acci
-
dent,
tampering, or substitution of non–Graco component parts. Nor shall Graco
be liable for malfunction, dam
-
age
or wear caused by the incompatibility with Graco equipment of structures, accessories, equipment or mate
-
rials not supplied by Graco, or the improper design, manufacture, installation, operation or maintenance of
structures,
accessories, equipment or materials not supplied by Graco.
This
warranty is conditioned upon the prepaid return of the equipment
claimed to be defective to an authorized
Graco distributor for verification of the claim. If the claimed defect is verified, Graco will repair or replace free of
charge
any defective
parts. The equipment will be returned to the original purchaser transportation prepaid. If
inspection
of the equipment does not disclose any defect in material or workmanship, repairs will be made at a
reasonable
charge, which charges may include the costs of parts, labor and transportation.
DISCLAIMERS AND LIMIT
ATIONS
THE
TERMS OF THIS W
ARRANTY CONSTITUTE PURCHASER’S SOLE AND EXCLUSIVE REMEDY AND ARE IN LIEU OF ANY
OTHER
WARRANTIES
(EXPRESS OR IMPLIED), INCLUDING W
ARRANTY OF MERCHANT
ABILITY OR W
ARRANTY OF FITNESS FOR A P
AR-
TICULAR PURPOSE, AND OF ANY NON–CONTRACTUAL LIABILITIES, INCLUDING PRODUCT LIABILITIES, BASED ON NEGLI-
GENCE
OR
STRICT LIABILITY
. EVER
Y FORM OF LIABILITY FOR DIRECT
, SPECIAL OR CONSEQUENTIAL DAMAGES OR LOSS IS
EXPRESSLY
EXCLUDED
AND DENIED. IN NO CASE SHALL GRACO’S LIABILITY EXCEED THE AMOUNT OF THE PURCHASE PRICE.
ANY
ACTION FOR BREACH OF W
ARRANTY MUST BE BROUGHT WITHIN TWO (2) YEARS OF THE DA
TE OF SALE.
EQUIPMENT
NOT COVERED BY GRACO W
ARRANTY
GRACO
MAKES NO W
ARRANTY
, AND DISCLAIMS ALL IMPLIED W
ARRANTIES
OF MERCHANT
ABILITY AND FITNESS FOR A P
AR-
TICULAR
PURPOSE, WITH RESPECT T
O ACCESSORIES, EQUIPMENT
, MA
TERIALS, OR COMPONENTS SOLD BUT NOT MANU
-
FACTURED
BY GRACO.
These
items sold, but not manufactured by Graco (such as electric motor
, switches, hose,
etc.)
are subject to the warranty
, if any
, of their manufacturer
. Graco will provide purchaser with reasonable as
-
sistance
in making any claim for breach of these warranties.
Factory
Branches:
Atlanta, Chicago, Dallas, Detroit, Los Angeles, Mt. Arlington (N.J.)
Subsidiary and Affiliate Companies:
Canada, England, Switzerland, France, Germany
, Hong Kong, Japan; Korea
GRACO
INC.
P
.O. BOX 1441
MINNEAPOLIS, MN
55440–1441
PRINTED
IN U.S.A.
307–71
1 1–85
Revised 10–92
