Graco Pulse TLM - Obround Tank; Non-Standard Tanks

Tank Specifications
18 3A5411J
Obround Tank:
• Maximum Volume = 999,999 gal-
lons or liters.
• Tank end walls must be flat; they
cannot be any other shape includ-
ing belled (F
IG. 17). If applicable,
use non-standard tank.
Non-Standard Tanks:
• Maximum Volume = 999,999 gallons or
liters.
• The volume at various distances from
the TLM can be entered into the Pulse
software.
• A maximum of 30 points can be inputted
into the Pulse software.
• Maximum height of 30 ft. (9.14 m).
FIG. 17
max height 30 ft. (91.4 m)
max
length 30 ft
(9.14 m)
max
width 30 ft
(9.14 m)
