Graco Pulse TLM - Technical Specifications

Technical Specifications
3A5411J 19
Technical Specifications
California Proposition 65
Tank Level Monitor (TLM)
US Metric
Compatible Fluids oil, waste oil, automatic transmission fluid (ATF), anti-freeze,
windshield washer solution, and waste water
Ultrasonic Tank Depth Measurement
range
5 in. to 30 ft. 12.7 cm to 9.14 m
Fluid Level Measurement Accuracy +/- 1.8 in. +/- 4.57 cm
Mounting 1.5 in. and 2 in. threaded NPT connector
Clearance: Height above tank for TLM 7.5 inches 19.1 cm
Weight (with batteries installed) 1.25 lb. 567 g
RF Frequency Band 2400-2483.5 MHz
Maximum RF Transmit Power 6.3 mW (8 dBm)
Operating Temperature Range
(Display will not function below 32°F
(0°C)
-22° F to 185° F - 30° C to 85° C
Storage Temperature Range -40°F to 185°F -40°C to 85°C
Batteries Four AA alkaline
Battery Life 5 years
Enclosure (Ingress Protection) IP65 IP65
Tanks
Vertical Tanks
Maximum Volume 999,999 gallons 999,999 liters
Maximum Height 30 ft. 9.14 m
Cylindrical Tanks
Maximum Volume 999,999 gallons 999,999 liters
Maximum Height 30 ft. 9.14 m
Maximum Length 30 ft. 9.14 m
Obround Tanks
Maximum Volume 999,999 gallons 999,999 liters
Maximum Height 30 ft. 9.14 m
Maximum Length 30 ft. 9.14 m
Maximum Width 30 ft. 9.14 m
Strapping Table
Maximum Volume 999,999 gallons 999,999 liters
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov.
