Graco Reactor 2 E-30 - Pressure Relief Procedure

PressureReliefProcedure
Pressure Pressure
Pressure
Relief Relief
Relief
Procedure Procedure
Procedure
FollowthePressureReliefProcedure
wheneveryouseethissymbol.
Thisequipmentstayspressurizeduntilpressure
ismanuallyrelieved.Tohelppreventserious
injuryfrompressurized󰘱uid,suchasskininjection,
splashing󰘱uidandmovingparts,followthe
PressureReliefProcedurewhenyoustopspraying
andbeforecleaning,checking,orservicing
equipment.
The Fusion AP gun is shown.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressureingunandperformgun
shutdownprocedure.Seeyourgunmanual.
4.Closegun󰘱uidinletvalvesAandB.
5.Shutofffeedpumpsandagitator,ifused.
6.Route󰘱uidtowastecontainersorsupplytanks.
TurnPRESSURERELIEF/SPRAYvalves(SA,
SB)toPRESSURERELIEF/CIRCULATION
.
Ensuregaugesdropto0.
7.Engagegunpistonsafetylock.
8.Disconnectthegunairlineandremovethegun
󰘱uidmanifold.
