Repair
7.PerformPressureReliefProcedure,page45.
8.Removethesystemframefromthe󰘱oorand
L-brackets.
9.Removetwoboltsandnutsandfoldtheelectrical
enclosurebackward.
10.Removescrews(21)andmotorshroud(11).
Restthemotorshroudbehindthemotorwithout
strainingthefanpowercable.
Note
Examinebearinghousing(103)and
connectingrod(105).Ifthesepartsneed
replacing,󰘰rstremovethepump(106),
seeRemovePump,page53.
11.Removecover(60)andscrews(21).
12.Removecyclecounter(121)fromhousingby
removingscrew(122).
13.Disconnectpumpinletandoutletlines.Remove
screws(113),washers(115),andbearing
housing(103).
NOTICE NOTICE
NOTICE
Donotdropgearcluster(104)whenremoving
drivehousing(102).Gearclustermaystay
engagedinmotorfrontendbellordrive
housing.
14.Removescrews(112,119)andwashers(114)
andpulldrivehousing(102)offmotor(101).
Note
TheAsidedrivehousingincludescycle
counterswitch(121).Ifreplacingthis
housing,removescrews(122)and
switch.Reinstallscrewsandswitchon
newdrivehousing.
Figure4
56 333024S
