Parts
QuantityRef
Part Description
272010 272011 272012 272110 272111 272112
21 118444
SCREW, mch, slot hex
wash hd; 1/2 in. x #10–24
12 12 12 12 12 12
22 117683
SCREW, mch, phil pan
hd; 1.5 in. x #6–32
888888
23 113796
SCREW, flanged, hex hd;
3/4 in. x 1/4–20
11 13 13 11 13 13
24112731NUT,hex,flanged 666666
25 111800
SCREW, cap, hex hd;
7/32 in. x 5/16 –18
444444
26 111218
CAP, tube, square
222222
27 110996
NUT, hex, flange head
888888
28 104859
SCREW, tapping pnhd;
5/16 in. x #10–16
222222
29 103181
WASHER, lock ext
444444
30100020WASHER,lock 222222
31 115836
GUARD, fing er
111111
32 24U847 FAN, cooling, 120mm,
24vdc
222222
33 24R685
ENCLOSURE, lower,
dinrail; includes 33a-33d
111111
33a
24U849
KIT, module, din rail,
heater; see Heater and
Transformer Terminal
Block Module, page 87
111111
33b 16W667
INSULATOR, FOAM
111111
33c
---
COVER, b otto m, di nrai l
111111
33d
113505
NUT, keps, hex hd
111111
34 151395
WASHER, flat
444444
35120685GROMMET 222222
36 114269
GROMMET, rubber
111111
37 125625
TIE, cable, fir tree
5
66
5
66
38 127277
BOL T, carriage, 1/2-13 x
3.5 l
444444
39127278NUT,keps,hex 444444
40127282GROMMET,rubber 444444
41 16X095
CONNECTOR, power,
male, 4 pin
111111
42
★
125871TIE,cable,7.5in. 252525252525
43
★
24K207
KIT, fts, rtd, single hose
111111
74
333024F
