Models
309574L 3
Models
E SERIES
E-XP SERIES
* Full load amps with all devices operating at maximum capabilities. Fuse requirements at various flow rates and mix
chamber sizes may be less.
** E-20 and E-XP1 with 210 ft (64.1 m) hose; E-30 and E-XP2 with 310 ft (94.6 m) hose.
Part No.,
Series Model
Voltage
(phase)
Full
Load
Peak
Amps*
System
Watts**
Heater
Watts
Flow
lb/min
(kg/min)
Output per
Cycle (A + B)
gal. (liter)
Maximum
Fluid Working
Pressure psi
(MPa, bar)
246025, D E-20 230V (1) 48 11,100 6,000 20 (9) .0104 (.0395) 2000 (14, 140)
246026, C E-30 230V (1) 78 17,900 10,200 30 (13.5) .0272 (0.1034) 2000 (14, 140)
246030, D E-20 380V (3) 24 11,100 6,000 20 (9) .0104 (.0395) 2000 (14, 140)
246031, C E-30 380V (3) 34 17,900 10,200 30 (13.5) .0272 (0.1034) 2000 (14, 140)
246034, D E-20 230V (3) 32 11,100 6,000 20 (9) .0104 (.0395) 2000 (14, 140)
246035, C E-30 230V (3) 50 17,900 10,200 30 (13.5) .0272 (0.1034) 2000 (14, 140)
248657, A E-30
with
15.3kW
230V (1) 100 23,000 15,300 30 (13.5) .0272 (0.1034) 2000 (14, 140)
248658, A E-30
with
15.3kW
230V (3) 62 23,000 15,300 30 (13.5) .0272 (0.1034) 2000 (14, 140)
248659, A E-30
with
15.3kW
380V (3) 35 23,000 15,300 30 (13.5) .0272 (0.1034) 2000 (14, 140)
Part No.,
Series Model
Voltage
(phase)
Full
Load
Peak
Amps*
System
Watts**
Heater
Watts
Flow
gpm
(lpm)
Output per
Cycle (A + B)
gal. (liter)
Maximum Fluid
Working Pressure
psi (MPa, bar)
246024, C E-XP1 230V
(1)
69 15,800 10,200 1 (3.8) .0104 (.0395) 2500 (17.2, 172)
246028, C E-XP2 230V
(1)
100 23,000 15,300 2 (7.6) .0203 (.0771) 3500 (24.1, 241)
246029, C E-XP1 380V
(3)
24 15,800 10,200 1 (3.8) .0104 (.0395) 2500 (17.2, 172)
246032, C E-XP2 380V
(3)
35 23,000 15,300 2 (7.6) .0203 (.0771) 3500 (24.1, 241)
246033, C E-XP1 230V
(3)
43 15,800 10,200 1 (3.8) .0104 (.0395) 2500 (17.2, 172)
246036, C E-XP2 230V
(3)
62 23,000 15,300 2 (7.6) .0203 (.0771) 3500 (24.1, 241)
