Graco Reactor A-25 User Manual

Proportioner Models
3A1570V 3
Proportioner Models
All proportioners can be configured to operate on 350-415 V (4 wire), 200-240 V (3 wire), or 200-240 V 1Ø.
Systems
All systems include a proportioner, spray gun, and 60 ft (18.3 m) of heated hose.
Part
Maximum Fluid Working
Pressure
psi (MPa, bar)
Maximum Air Working
Set Pressure
psi (kPa, bar)
Includes:
Approvals
DataTrak
(cycle count only)
Wheels
262572 2000 (14, 138) 80 (550, 5.5) --- ---
262614 2000 (14, 138) 80 (550, 5.5) 24A592
✔
24Y164 3500 (24, 241) 100 (689, 6.9) --- ---
24Y165 3500 (24, 241) 100 (689, 6.9) 24A592
✔
Part
Maximum Working
Pressure
psi (MPa, bar)
Proportioner
Heated Hose Gun
50 ft (15 m) 10 ft (3 m) Model Part
P22614 2000 (14, 138) 262614 246678 246050
Probler
®
P2
GCP2R1
AP2614 2000 (14, 138) 262614 246678 246050
Fusion
™
AP
246101
CS2614 2000 (14, 138) 262614 246678 246050
Fusion
™
CS
CS01RD
P22572 2000 (14, 138) 262572 246678 246050
Probler
®
P2
GCP2R1
AP2572 2000 (14, 138) 262572 246678 246050
Fusion
™
AP
246101
CS2572 2000 (14, 138) 262572 246678 246050
Fusion
™
CS
CS01RD
P2Y165 3500 (24, 241) 24Y165 246679 246055
Probler
®
P2
GCP2R1
APY165 3500 (24, 241) 24Y165 246679 246055
Fusion
™
AP
246101
P2Y164 3500 (24, 241) 24Y164 246679 246055
Probler
®
P2
GCP2R1
APY164 3500 (24, 241) 24Y164 246679 246055
Fusion
™
AP
246101
Conforms to ANSI/UL
Std. 499 Certified to
CAN/CSA Std.
C22.2 No. 88
3172585
