Graco REACTOR E-30 Repair Guide

Reactor Assembly
309574L 61
Proportioner Module
245956 Module, for E-20 and E-XP1
245957 Module, for E-30
245959 Module, for E-XP2
301
302
303
304
305
306A
*307308
309
**310
311
312
313
314
315
316
317
318
319
*308
314
TI2511A
TI3250a
321
Detail of Cycle Counter Switch
1
Flat side faces up.
1
320
306B
311
310**
316
1
325
324
326

Graco REACTOR E-30 Specifications

General

Maximum Fluid Temperature	190°F (88°C)
Max Fluid Pressure	3000 psi
Heater Wattage	6000 W
Power Requirements	3-phase, 230V
Type	Electric
Heater Voltage	230V
Fluid Outlet Size	3/8 in
Voltage	230V
Spray Tip Size	0.015 - 0.035 in
