Repair
309574L 39
245979 Temperature Control Board
FIG. 13. Temperature Control Board
1
Apply 110009 thermal heatsink compound to mating surfaces.
1
TI2572a
J1
J5
J13
J9
J2
J8
D15
D27
D19
D26
D18
D13
D14
B
A
