Reactor Assembly
309574L 57
51▲
LABEL, warning
198278 198278 198278 198278 198278 198278 1
52 CABLE, harness,
filter
15B385 15B385 15B385 15B385 15B385 15B385 1
65 ELBOW, swivel;
3/4 npt(m) x 3/4
npt(f)
160327 160327 160327 160327 160327 160327 160327 160327 160327 2
ELBOW, swivel;
3/4 npt(m) x 1”
npt(f)
118463 118463 118463 2
71 SCREW, machine 104590 104590 104590 104590 104590 104590 2
72 BRACKET, heater
15C733 15C733 15C733 15C733 15C733 15C733 15C733 15C733 15C733
2
BRACKET, heater
15C733 15C733 15C733
4
73 WASHER, lock
103181 103181 103181 103181 103181 103181 2
76 CAPACITOR 244733 244733 244733 244733 244733 244733 1
77 BRACKET
197999 197999 197999 197999 197999 197999 1
86 CABLE, overtem-
perature, jumper;
see pages 59, 60)
15B769 15B769 15B769 15B769 15B769 15B769 15B769 15B769 15B769 2
CABLE, overtem-
perature, jumper;
see page 60)
15B769 15B769 15B769 4
92 CABLE, harness,
power; see pages
68-70
15B511 15B511 15B511 15B511 15B511 15B511 1
CABLE, harness,
power; see pages
68-70
15B382 15B382 15B382 15B382 15B382 15B382 1
95 BOLT; hex hd;
3/8-16
516595 516595 516595 516595 516595 516595 516595 516595 516595 2
BOLT; hex hd;
3/8-16
516595 516595 516595 4
96 LOCKWASHER;
3/8
100133 100133 100133 100133 100133 100133 100133 100133 100133 2
LOCKWASHER;
3/8
100133 100133 100133 4
97 NUT, channel 118446 118446 118446 118446 118446 118446 118446 118446 118446 2
NUT, channel
118446 118446 118446 4
102 STRAP, motor 15B107 15B107 15B108 15B108 15B107 15B107 15B108 15B108 15B107 15B107 15B108 15B108 1
121 LABEL 15B811 15B537 15B538 15B544 15B811 15B537 15B538 15B544 15B811 15B537 15B538 15B544 1
122* In-rush Current
Limiter; page 54
288359 288359 288359 288359
* Uses 1.6Amp, Slo-Blow Fuse 120614. This fuse must be slow blow for In-rush Current Limiter to function properly.
Ref.
No. Description
Reactor Models
Qty
246024
E-XP1
246025
E-20
246026
E-30
246028
E-XP2
246029
E-XP1
246030
E-20
246031
E-30
246032
E-XP2
246033
E-XP1
246034
E-20
246035
E-30
246036
E-XP2
