Name: Graco Reactor H-40 Series
Brand: Graco
Rating: 5 (1 reviews)

To Next Page

To Previous Page

Contents

2 312064N

Contents

Contents ..................................2

Supplied Manuals ..........................2

Models ...................................3

Simplified Schematic, Motor Controls ..........5

1-Phase Motor ..........................5

3-Phase Motor ..........................6

Simplified Schematic, Heater Controls .........7

Simplified Schematic, Power Connections ......8

Detailed Schematic, Motor Controls (1-Phase Motor)

......................................10

Detailed Schematic, Motor Controls (3-Phase Motor)

......................................11

Detailed Schematic, Heater Controls ..........12

Graco Standard Warranty ...................14

Graco Information .........................14

Supplied Manuals

The following manuals are shipped with the Reactor

™

Proportioner. Refer to these manuals for detailed equip-

ment information.

Manuals are also available at www.graco.com.

Reactor Hydraulic Proportioner

Part Description

312062 Reactor Hydraulic Proportioner, Oper-

ation Manual (English)

312063 Reactor Hydraulic Proportioner,

Repair-Parts Manual (English)

313539 Reactor H-VR Proportioner, Opera-

tion Manual (English)

313540 Reactor H-VR Proportioner,

Repair-Parts Manual (English)

Graco Reactor H-40 Series Electrical Diagrams

Other manuals for Graco Reactor H-40 Series
