Graco Reactor H-40 Series Electrical Diagrams

Models
312064N 3
Models
H-25 SERIES
H-40 SERIES
H-50 SERIES
H-VR SERIES
Part, Series
Full Load
Peak Amps*
Per Phase
NominalVoltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate◆
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
255400, F 69 200-240 V (1) 15,960 8,000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255401, F 46 200-240 V (3) 15,960 8,000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255402, F 35 350-415 V (3) 15,960 8,000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255406, F 100 200-240 V (1) 23,260 15,300 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255407, F 59 200-240 V (3) 23,260 15,300 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255408, F 35 350-415 V (3) 23,260 15,300 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
Part,
Series
Full Load
Peak Amps*
Per Phase
NominalVoltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate◆
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
★253400, E 100 200-240 V (1) 23,100 12,000 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253401, E 71 200-240 V (3) 26,600 15,300 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253402, E 41 350-415 V (3) 26,600 15,300 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253407, E 95 200-240 V (3) 31,700 20,400 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253408, E 52 350-415 V (3) 31,700 20,400 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
Part,
Series
Full Load
PeakAmps*
Per Phase
Nominal Voltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate◆
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
★253725, E 100 200-240 V (1) 23,100 12,000 52 (24) 0.073 (0.28) 1.64:1 1700 (11.7, 117)
253726, E 71 200-240 V (3) 26,600 15,300 52 (24) 0.073 (0.28) 1.64:1 2000 (13.8, 138)
253727, E 41 350-415 V (3) 26,600 15,300 52 (24) 0.073 (0.28) 1.64:1 2000 (13.8, 138)
256505, E 95 200-240 V (3) 31,700 20,400 52 (24) 0.073 (0.28) 1.64:1 2000 (13.8, 138)
256506, E 52 350-415 V (3) 31,700 20,400 52 (24) 0.073 (0.28) 1.64:1 2000 (13.8, 138)
Part,
Series
Full Load
Peak Amps*
Per Phase
NominalVoltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate◆
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
256886 71 200-240 V (3) 26,600 15,300 15 (4) Variable Variable 3500 (24.1, 241)
256887 41 350-415 V (3) 26,600 15,300 15 (4) Variable Variable 3500 (24.1, 241)
