Component Identification
7
Component Identification
English Français Dutch
A
Main Power Switch
B
Nozzle Storage
C
Hopper
D
Hopper Connect/Disconnect
E
Graco RotoFlex™ HD Pump
F
Material Outlet
H
Air Outlet
K
Fluid Flow Regulator and
Pressure Gauge
L
Gun Nozzle (5 sizes)
M
Gun (see manual 310616)*
P
Prime Switch
R
Power Cord
S
Pump Access Screw
T
Hose - 25-ft.
U
Material Thickness Gauge
V
Cleaning Ball
W
Spare Hose Gaskets
