Spray Techniques
23
System Adjustment
WARNING
Read warnings, page 4.
Fluid flow is controlled with the
fluid flow regulator knob (K) and
displayed on the gauge.
Gun air flow is regulated using air
valve (aa) located on gun handle.
1 Open air valve (aa). 2 Test spray pattern on card-
board. Hold gun 18 to 30 in.
(457 to 762 mm) from surface.
Use this spray distance for
most applications. Overlap
each stroke 50% in a circular
motion.
3 Adjust air valve (aa) and/or
fluid flow regulator (K) on
sprayer to achieve desired
spray pattern.
123
123
ti4303a
K
ti3999a
aa
cc
ti4000a
aa
ti4004a
ti4303a
K
ti3999a
aa
cc
