Graco RTX2500 - Page 25

RTX1400si Sprayer
3A3258H 25
RTX1400si Sprayer (cont’d)
Ref. Torque Ref. Torque
15-20 in-lb (1.7 - 2.3 N•m) 27-32 in-lb (3.1 - 3.6 N•m)
75-95 in-lb (8.5 - 10.7 N•m) 90-110 in-lb (10.2 - 12.4 N•m)
50-70 in-lb (5.6 - 7.9 N•m)
65-85 in-lb (7.3 - 9.6 N•m) then
back off 1/4 turn
40-50 in-lb (4.5 - 5.7 N•m)
1
5
2
6
3
8
4
21
16
4
54
6
29
80
80
60
26
38
35
27
19
65
66
3
68
69
55
93
77
51
ti27872a
61
5
8
2
See page 33.
