Component Identification
3A3258H 7
Component Identification
RTX1400si
C
D
F
H
J
K
G
B
A
E
R
P
N
M
ti27337a
S
W
Y
A
Handle
B
Toolbox
C
Power Cord
D
Pump Access Panel
E
RotoFlex™ II Pump
F
Pump Hose Outlet
G
Air Hose Outlet
H
Material Flow Gauge
J
Material Flow Control
K
ON/OFF Switch
M
Material Hopper
N
Burp Guard
P
Material/Air Hose
R
Material Thickness Gauge
S
Nozzle
W
Gun
Y
Air control valve
Model/Serial Tag (Not shown, located
on bottom of unit.)
