Graco RTX2500 - RTX2000 pi & RTX2500 pi

Component Identification
8 3A3258H
RTX2000pi & RTX2500pi
R
P
S
W
H
J
K
D
F
G
C
B
A
ti27338a
N
M
X
Y
A
Handle
B
Toolbox
C
Power Cord
D
Pump Access Panel
E
RotoFlex™ II Pump
F
Pump Hose Outlet
G
Air Hose Outlet
H
Material Flow Gauge
J
Material Flow Control
K
ON/OFF Switch
M
Material Hopper
N
Burp Guard
P
Material/Air Hose
R
Material Thickness Gauge
S
Nozzle & retaining ring
W
Gun
X
Prime Valve
Y
Air control valve
Model/Serial Tag (Not shown, located
on bottom of unit.)
