RTX2000pi Sprayer
28 3A3258H
RTX2000pi Sprayer (cont’d)
Ref. Torque Ref. Torque
15-20 in-lb (1.7 - 2.3 N•m) 90-110 in-lb (10.2 - 12.4 N•m)
75-95 in-lb (8.5 - 10.7 N•m)
9-11 in-lb (1- 1.2 N•m)
50-70 in-lb (5.6 - 7.9 N•m)
65-85 in-lb (7.3 - 9.6 N•m) then
back off 1/4 turn
40-50 in-lb (4.5 - 5.7 N•m) 120-130 in-lb (13.6 - 14.7 N•m)
27-32 in-lb (3.1 - 3.6 N•m)
