Graco Smart Seat - FORWARD-FACING INSTALLATION

D
A
36
1. Test base for secure installation. See TFDUJPOTBOE
GPSCBTFJOTUBMMBUJPOQ A.
2. Push in B and rotate knobs C on both sides of child
restraint to unlock position.
3. Place on base in forward-facing position D.
4. Rotate knobs on both sides to lock seat to base E.
You will see lock symbols in windows on side of base
as shown H.
5. If you see the red ags up in the child restraint
seating area F and you see the unlock symbol I
then seat is not secured to base.
6. Check seat is secure by moving front to back and left
to right at the belt path G. Base should not move
more than 1 inch ( 2.54 cm). If belt loosens or
lengthens, repeat procedure.
Note: See i5FUIFS6TFwQ to attach tether.
12.0 FORWARD-FACING INSTALLATION
F
