Graco Smart Seat - Adjusting Head Support; Harness Straps

51
A
51
18.3 Adjusting Head Support/
Harness Straps
Failure to properly
adjust the harness
straps for your child
increases the risk of serious injury or death
in the event of a sharp turn, sudden stop or
crash.
tBEFORE adjusting the head support height,
have your child lean forward slightly.
t4RVFF[FUIFSFEBEKVTUNFOUIBOEMF
A on
top of seat and pull head support up until it
snaps into one of the 6 height positions.
t5PMPXFSTRVFF[FSFEBEKVTUNFOUIBOEMF
and push head support down.
tCHECK to make sure it is securely snapped
into one of the 6 height positions by pulling
up on head support.
When using in rear-facing mode always use
one of the bottom 3 height positions B.
When using in forward-facing mode always
use one of the top 4 height positions B.
Refer to page 50 for harness strap
placement.
B
