19.1 Storing Harness
Harness must be stored during Booster Mode.
1. Push the clip at the end of crotch strap through bottom of seat and pull out
through the seat and seat cover A.
2. Rotate bottom of head support pad up and attach to back of head support
pad with hook and loop tape B.
3. Disconnect snaps on seat cover
C.
4. Move harness straps behind seat cover D.
5. Disconnect snaps or hook and loop tape (on certain models) and move
shoulder straps behind head support pad E.
6. Open door behind seat cover F.
7. Insert harness buckle and crotch straps into harness storage compartment G.
8. Close door H.
9. Re-attach snaps on seat cover I.
19.0 BOOSTER INSTALLATION
