Graco XM Series User Manual

Appendix B
94 312359R
Metering Diagram with Remote Mix Manifold
XLXL
XM Metering Diagram with
Remote Mix Manifold
XL
XL
Linear
Transducers
H
O
P
P
E
R
6500
Air
Motor
Controls
Double
Motor Pilots
Air
Reg
NOTE: Additional guns may only be
added after integration hose and mixer
Reed
Switches
Control
Valves
Mix
Manifold
250 HF or
180 HP
6500
Air
Motor
Gravity Feed
or Pump
Feed
Sample and
Test Valves
220 HF or
145 HP
H
O
P
P
E
R
H
E
A
T
E
R
H
E
A
T
E
R
Circulation
ON/OFF
F
L
U
S
H
Recirculation Back
Pressure Control
Mixers
Fluid Line
These hose isolation check valves must be
added when the mix manifold is remote.
This ensures that pressure transducers
read pump output and cavitation, and not
just dampened hose pressure.
Settable ‘B’
Balancing
Restriction
Integration
Hose 3/8 x 25
ft minimum
Control Cable
Air Signal
Spray Gun 3
Spray Gun 2
Spray Gun 1
Remote
Shutoff and
Check Valves
Shutoff and
Hose Isolation
Check Valves
