Appendix I Gram factory settings for AKCC550A (U/KG/FG cabinets)
Gram default
settings U models
(Solid door)
Gram default
settings KG models
(Glass door)
Gram default
settings MIDI FG
models (Glass
door)
X = Parameters
to be
considered/set
by installer
Configuration of alarm relay
The alarm relay will be activated upon an alarm signal from
the following groups:
1 - High temperature alarms 2 - Low temperature alarms 4 -
Sensor error
8 - Digital input enabled for alarm 16 - Defrosting alarms
32 - Miscellaneous 64 - Injection alarms
The groups that are to activate the alarm relay must be set
by using a numerical value which is the sum of the groups
that must be activated.
(E.g.: a value of 5 will activate all high temperature alarms
and all sensor error and 0 will cancel the relay
function).
Temperature measured with S5 sensor
Status on DI1 input. on/1=closed
Actual defrost time (minutes)
Temperature measured with S3 sensor
Status on night operation (on or off) 1=on
Temperature measured with S4 sensor
Run time of thermostat (cooling time) in minutes
Temperature of evaporator outlet temp.
Superheat across evaporator
Reference of superheat control
Opening degree of AKV valve
Evaporating pressure Po (relative)
Evaporator temperature To (Calculated)
Temperature measured with S6 sensor
(product temperature)
Status on DI2 output. on/1=closed
Air temperature . Weighted S3 and S4
Measured temperature for alarm thermostat
Status on relay for cooling
Status on relay for defrost
Status on relay for rail heat
Status on relay for alarm
Status on relay for light
Status on relay for valve in suction line
Status on relay for compressor 2
Temperature measured with S5B sensor
Temperature measured with S3B sensor
Status on relay for hot gas- / drain valve
Status on relay for heating element in drip tray
Status on relay for night blinds
Status on relay for defrost B
Status on relay for heat function
Readout of the actual rail heat effect
