Gram Eco Plus U 70 - Appendix I (Danfoss AKCC550 A Settings)

Appendix I Gram factory settings for AKCC550A (U/KG/FG cabinets)
Appendix I (Danfoss AKCC550A settings)
Menu survey
SW = 1.9x
Parameter
Gram default
settings U models
(Solid door)
Gram default
settings KG models
(Glass door)
Gram default
settings MIDI FG
models (Glass
door)
X = Parameters
to be
considered/set
by installer
Function
Code
Normal operation
Temperature (setpoint)
- - -
2
2
-18
X
Thermostat
Differential
r01
2
2
2
Max. limitation of setpoint setting
r02
12
12
-5
X
Min. limitation of setpoint setting
r03
-25
1
-22
X
Adjustment of temperature indication
r04
0
0
0
Temperature unit (°C/°F)
r05
°C
°C
°C
Correction of the signal from S4
r09
0
0
0
Correction of the signal from S3
r10
0
0
0
Manual service, stop regulation, start regulation (-1, 0, 1)
r12
1
1
1
Displacement of reference during night operation
r13
0
0
0
Define thermostat function
1=ON/OFF, 2=Modulating
r14
1
1
1
Definition and weighting, if applicable, of thermostat sen-
sors - S4% (100%=S4, 0%=S3)
r15
0
0
0
Time between melt periods
r16
0
0
0
Duration of melt periods
r17
0
0
0
Temperature setting for thermostat band 2. As differential
use r01
r21
2
2
2
Correction of the signal from S6
r59
0
0
0
Definition and weighting, if applicable, of thermostat sen-
sors when night cover is on. (100%=S4, 0%=S3)
r61
0
0
0
Heat function
Neutral zone between refrigeration and heat function
r62
N/A
N/A
N/A
Time delay at switch between refrigeration and heat function
r63
N/A
N/A
N/A
Alarms
Delay for temperature alarm
A03
60
60
60
Delay for door alarm
A04
5
5
5
Delay for temperature alarm after defrost
A12
90
90
90
High alarm limit for thermostat 1
A13
35
35
35
X
Low alarm limit for thermostat 1
A14
-35
-35
-35
X
High alarm limit for thermostat 2
A20
35
35
35
Low alarm limit for thermostat 2
A21
-35
-35
-35
High alarm limit for sensor S6 at thermostat 1
A22
8
8
8
Low alarm limit for sensor S6 at thermostat 1
A23
-30
-30
-30
High alarm limit for sensor S6 at thermostat 2
A24
8
8
8
Low alarm limit for sensor S6 at thermostat 2
A25
-30
-30
-30
S6 alarm time delay
With setting = 240 the S6 alarm will be omitted
A26
240
240
240
Alarm time delay or signal on the DI1 input
A27
5
5
5
Alarm time delay or signal on the DI2 input
A28
30
30
30
Signal for alarm thermostat. S4% (100%=S4, 0%=S3)
A36
0
0
0
Delay for S6 (product sensor alarm) after defrost
A52
90
90
90
Compressor
Min. ON-time
c01
0
0
0
