Material No. 1 447 263
Removal
1 Engage the backrest (3) in the
foremost position.
2 Unhook the seat cushion (1) from the
spring assembly (5). To do this, first
pull the snap lock grip (2) backwards
and then upwards.
3 Grasp the seat cushion (1) with both
hands at the front left and right, press
downwards and remove by pulling it
out forwards.
Installation
1 Place the seat cushion (1) on the spring
assembly (5). The two holders (6) at the
bottom of the seat cushion (1) must be
level with the hooks (4) on the spring
assembly (5).
Note:
If a seat switch is provided, ensure that
the pressure springs and the switch
bracket are correctly seated when
installing the seat cushion (1) to
guarantee the proper functioning of the
seat switch (see Chapter 3.8).
2 Press the seat cushion (1) down at the
front left and right and push it
backwards onto the two hooks (4) with
the two holders (6).
3 Press down on the seat cushion (1) at
the rear centre until the snap lock grip
(2) engages.
Note:
Check the function of the seat switch:
Press the front of the seat cushion (1)
several times at the left and right to
check whether the seat switch makes
audible contact (see Chapter 3.8).
