Grammer MSG45/421 - Maintenance

GRAMMER repair manual for seat MSG45/421 – February 2020
Material No. 1 447 263
3.11 Removing/installing the end stop (buffer)
Page 1 of 1
Removal, installation
1 Unhook the bellows on the rear of the
lower suspension component (1), push
upwards and fix (see Chapter 3.5).
2 Press the end stop (2) out of the lower
suspension component (1).
3 Installation is carried out in reverse
order.
3518
1
2
