Material No. 1 447 263
About this manual
This repair manual contains information and instructions for performing repair work
on the GRAMMER seat MSG45 with seat top 421.
The seat MSG45 with seat top 421 forms the basis of the illustration in the repair
manual. Any differences resulting from technical deviations in the work steps
(due to any seat design variations) are described in the text or in separate chapters.
All preparations to be made before starting work are listed at the beginning of each
chapter. These tasks are described in their own chapters and are carried out without
any of the preparations which may be listed there.
Within each chapter of this repair manual, all parts shown in the images are
numbered starting with "1". Each part is addressed within the chapter with the same
item number.
Only the item numbers in the valid spare parts catalogues can be used for spare
parts orders.
The work is described for the dismantled seat.
If the installation situation allows it, some work can also be carried out on an
installed seat.
For this reason, the surroundings of the installed seat must first be investigated for this
option before work is started. The safety specifications of the vehicle manufacturer
and those in Chapter 1 of this repair manual must always be complied with.
Any delivery variants requiring an explanation are also described in this repair
manual. Since the scope of delivery is based on the customer's order, certain
descriptions and illustrations of the seat fittings can differ.
The repair work is presented based on the seat for left-hand drive. The different
tasks must be carried out in a mirror image for repairs on vehicle designs with right-
hand drive.
If not otherwise indicated in the text, the directional information "front, back" and
"right, left" refer to the installed seat and the vehicle's direction of travel.
The layout has been developed in a way that makes it possible to later offer the
repair manual in the form of a CD-ROM/INTERNET/INTRANET.
General information on the seat!
Please contact the manufacturer about any assembly work required for the removal
and installation of the seat in the vehicle.
The seat has long-term lubrication (around 10 years). The lubrication points may
only be regreased with lubrication grease KFHC2N-50 DIN 51825 following repair
work on the points marked by (F) in the repair manual.
It is possible that not all fasteners are mentioned in this repair manual. It may be
necessary upon completion of the repair work that fasteners be inspected with
regard to their factory installation and their hold and tightness, and corrected
accordingly if needed.
