GRAND EFFECTS FBBRPCON30 - Page 14

Page 14
Fire Bowls and Inserts Premium Line
Automated Operation
CUSTOMER FURNISHED
BOWL
GRAND EFFECTS
MOUNTING BRACKETS
GRAND EFFECTS /
CSA APPROVED
BURNER ASSEMBLY
GRAND EFFECTS
SUPPORT PLATE
WHEN MOUNTED
IN BOWL TOP OF
BURNER ASSEMBLY
IS FLUSH WITH TOP
OF BOWL
26” MINIMUM
9”
MINIMUM
1.5”
MINIMUM
Figure 9. Customer-supplied Bowl
