Fire Bowls and Inserts Premium Line
Automated Operation
Page 21
WARNING
Model 100 Burner Assembly
In order to avoid the risk of property damage, serious injury, including
death, turn OFF power and gas at the control panel prior to initiating
troubleshooting steps. Turn power and gas ON once troubleshooting is
complete. Some steps may require power and gas to be temporarily ON
for verication, but turned OFF for repair (see bolded step).
Symptom Corrective Action
Burner goes On/Off 1. Is it going off because of wind? If so, how
windy? Slight breeze or gusty? If wind
related, rotate burner assembly in bowl so
wind is not blowing across pilot.
2. If using glass, make sure an open pilot
hood is used. Remove rock/glass away
from pilot area. Does it get better? How
much glass? Thin down glass on burner
assembly.
3. Remove all rock/glass from the burner
assembly. Does the problem go away?
4. If gas pressure is too low or main burner
is adjusted too low, the pilot will be too
small and unstable.
5. If burner shuts off after a 30-minute
period and then goes off and doesn’t
come back on, replace the ignition
module.
Pilot comes on but no
main burner
1. If possible, conrm that main gas
solenoid is energizing. If not possible,
replace the ignition module.
2. Main burner solenoid may have to be
replaced if buzzing. Look for signs for
overheating.
Main burner or pilot
does not shut off
1. If the valve is not opening or is dirty,
replace the gas manifold.
