WASHING MACHINE Series GWH / GWM / GWN
GENERAL DESCRIPTION
TECHNICAL DATA
GWH GENERAL DATA
Characteristics kg 8 kg 11 kg 14 kg 18 kg 24 kg 28
Load ratio 1:10 kg/
dm
3
4 ÷ 8 5.3 ÷ 10.5 6.75 ÷ 13.5 9 ÷ 18 12 ÷ 24 14 ÷ 28
DWS dynamic weighing
YES
Electronic and
mechanical imbalance
control
YES
Spin (rev/min)
G Factor
1165/400 1075/400 1075/400 980/400 980/400 915/350
Noise level (dB) < 65
Control GUIDO
®
Payment systems
Simple coin operation / Electronic coin operation / Central payment unit / Other systems available upon
request
Electrical heating
power (kW)
6/9 6/9/12 9/12 12/18 18 22
Motor power (kW) 1.14 1.66 2.37 3.36 4.6 4.6
Power supply
220-240V 1~50/60 Hz
230-240V 3~50/60 Hz
380-415V 3N~50/60 Hz
440-480V 3~60 Hz
220-240V 1~50/60 Hz
220-240V 3~50/60 Hz
380-415V 3N~50/60 Hz
440-480V 3~60 Hz
Net/gross weight (kg) 190/205 215/240 260/280 385/400 435/455 475/520
Dynamic floor load
(kN/Hz)
1.9 ± 0.5/19.4 2.2 ± 0.5/17.9 2.7 ± 0.5/17.9 4.0 ± 0.7/16.3 4.6 ± 1.1/16.3
5.0 ±
1.1/15.25
Porthole diameter
(mm)
330 410 460
GWM - GWN GENERAL DATA
Characteristics kg 8 kg 11 kg 14 kg 18 kg 24 kg 28
Capacity ratio 1:10 kg 4 ÷ 8 5.3 ÷ 10.5 6.75 ÷ 13.5 9 ÷ 18 12 ÷ 24 14 ÷ 28
DWS dynamic weighing
YES
Electronic and
mechanical imbalance
control
YES
Spin (rev/min)
G Factor
820/200 760/200 760/200 490/100 490/100 490/100
Noise level (dB) < 70
Control G4-Wiz
®
Payment systems
Simple coin operation / Electronic coin operation / Central payment unit / Other systems available upon
request
Electric heating power
(kW)
6/9 6/9/12 9/12 12/18 18 22
Motor power (kW) 0.5 0.8 1.0 1.10 1.6 2.30
